Key Features
High clamping force for maximum rigidity
4.5° slim nose design for improved accessibility
Face coolant system for efficient cooling
Ultra-high precision (Runout ≤ 0.003 mm at 3×D)
High-speed balancing up to G2.5 / 25,000 RPM (or higher upon request)
Excellent vibration damping
Improved surface finish
Extended cutting tool life
Suitable for carbide end mills and carbide drill
Product Advantages
Superior Clamping Accuracy
Shrink fit technology provides 360° uniform clamping around the tool shank, eliminating deformation and delivering exceptional concentricity for precision machining.
01
Face Coolant Design
The integrated coolant outlet directs coolant precisely to the cutting edge, effectively reducing heat generation, improving chip evacuation, and extending tool life during heavy-duty machining.
02
High-Speed Performance
Balanced for high-speed machining, the holder minimizes vibration and enhances spindle stability, ensuring consistent cutting performance.
03
Slim 4.5° Nose
The slim profile reduces interference between the holder and the workpiece, making it ideal for deep cavities, narrow spaces, and complex mold machining.
04
Long Service Life
Manufactured using premium alloy steel with heat treatment and precision grinding, providing excellent wear resistance and dimensional stability.
05
Technical Specifications
Applications
The SW Shrink Fit Chuck is widely used in:
- Automotive Parts Manufacturing
- Aerospace Components
- Mold & Die Industry
- Precision Mechanical Parts
-
Medical Components
-
Energy Equipment
-
CNC Machining Centers
-
General Precision Manufacturing
